A wide, partly covered, deck, wraps around two sides of this small vacation retreat cabin home plan. The vaulted great room is naturally bright during the day. It's fully open to the nook and partially open to the kitchen along an eating bar that fronts the sink. Two bedrooms are downstairs; a loft, storage, and bathroom are above.
Plan 66144
Cordell
Photographs may show modifications made to plans. Copyright owned by designer.
- At a glance
-
1305
Square Feet
-
2
Bedrooms
-
2
Full Baths
-
2
Floors
- More about the plan
- Pricing
- Basic Details
- Building Details
- Interior Details
- Garage Details
- See All Details
Contact HPC Experts
Have questions? Help from our plan experts
is just a click away.
To help us answer your questions promptly, please copy and paste the following information in the fields below.
Let’s be social
Connect with us for the latest from HPC
Plan details
Basic Details
Building Details
Interior Details
Garage
What's Included in a Plan Set?
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Concept Plan Packages:
Includes PDF and DWG files of the:
Elevations
Floor Plan (s)
Roof Outline
The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
New to Plan Buying?
Cordell - 66144
Associated Designs
$725.00
- SKU:
- 101 - 30-185
- Plan Number:
- 66144
- Pricing Set Title:
- B [1201 - 1499]
- Designer Plan Title:
- 30-185
- Date Added:
- 05/07/2016
- Date Modified:
- 01/24/2024
- Designer:
- info@associateddesigns.com; jessica@associateddesigns.com
- Plan Name:
- Cordell
- Note Plan Packages: PDF Print Package:
- Best Value!
- Structure Type:
- Single Family
- Best Seller (Rank #):
- 32
- Square Footage: Total Living:
- 1305
- Square Footage: 1st Floor:
- 1047
- Square Footage: 2nd Floor:
- 258
- Floors:
- 2
- FLOORS_filter:
- 2
- Bedrooms:
- 2
- BEDROOMS_filter:
- 2
- Baths Full:
- 2
- FULL BATHROOMS_filter:
- 2
- Ridge Height:
- 23'8"
- Overall Exterior Depth:
- 40
- Overall Exterior Width:
- 42
- Main Floor Ceiling Height:
- 8'
- Available Foundations:
- Crawl Space
- Available Foundations:
- Concrete Slab
- Available Foundations:
- Basement
- Default Foundation:
- Crawl Space
- Available Walls:
- 2x6 Wood Frame
- Default Wall:
- 2x6 Wood Frame
- Ext Wall Material:
- Siding
- Lot Type:
- Narrow Lot (
- Lot Type:
- View Lot
- Lot Slope:
- Level Lot
- Roof Framing:
- Stick
- Snow Roof Load:
- 25.00
- Roof Pitch:
- 10/12
- Primary Style:
- Cottage
- Secondary Styles:
- Traditional
- Collections:
- Beach House Plans
- Collections:
- Cabin Plans
- Collections:
- Vacation Home Plans
- Interior Features:
- Fireplace/Wood Stove
- Interior Features:
- Great Room
- Interior Features:
- Loft
- Interior Features:
- Storage
- Kitchen Features:
- Breakfast Nook/Dining Area
- Utility Room Features:
- Main Floor Utility Room
- Exterior & Porch Features:
- Covered Porch
- Exterior & Porch Features:
- Deck
- Exterior & Porch Features:
- Wrap Around Porch
- Styles:
- Cottage House Plans
- Styles:
- Traditional House Plans
- Collections:
- 2 Story House Plans
- Collections:
- View Lot House Plans
- Collections:
- Narrow Lot House Plans
- Collections:
- Small House Plans
- Product Rank:
- 7352
- Note Plan Packages: Master Builder CAD Set:
- Unlimited Builds!
- Creation Date:
- 08/2010
- Plan SKU:
- 30-185
- Available Walls:
- 2x4 Wood Frame
- Max Price:
- 2575.00
- Min Price:
- 725.00
- Regions:
- Northwest House Plans/Oregon Home Plans
