Plan 20155

Arnett

Photographs may show modifications made to plans. Copyright owned by designer.

At a glance
1211 Square Feet
1 Bedrooms
2 Full Baths
2 Floors

Floor plan

A-Frame House Plan - Arnett 20155 - 2nd Floor Plan

A-Frame House Plan - Arnett 20155 - Optional Floor Plan

Free modification quote

Call Us 866-688-6970 or fill out our form.

Get Started

Cost to build report

How Much Will This Plan Cost To Build?

Find Out

Plan details

Basic Details

Building Details

Interior Details

Garage

What's Included in a Plan Set?

Construction Drawing Packages:

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:

Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.

Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.

Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.

Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.

Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.

Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.

Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.

Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.

Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

Concept Plan Packages:

Includes PDF and DWG files of the:

Elevations
Floor Plan (s)
Roof Outline

The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).

New to Plan Buying?

What You Need to Know About Purchasing Plans

You are about to embark on an exciting process, enjoy it!

Here is what you need to know about purchasing house plans from HPC:

• Each designer and architect plans are created with their own unique style and content. Please be sure to read the "What's included in a Plan Set" tab, and if you don't see what you are looking for, be sure to give us a call.
• The designs are not engineered. Check with the building department where the structure is being constructed to find out if an engineer's review is required. We can help facilitate engineering for your plan if you are unable to find a local professional who can assist you.
• Your building department may also require a site plan of your lot be included with your submittal for a building permit. A local design

professional in your area should be able to help you with this as well as evaluating your chosen plan to make sure it meets the local building requirements for weather and seismic conditions.
• Please read and understand your licensing agreement. This will clearly define what you can and can not do with your construction documents.
• Electronic formats of packages sales (PDF & CAD Files) are final. Printed construction documents may be exchanged with an exchange fee within 30 days of purchase.
• Unless purchasing an additional build license (one time additional or multi-build additional) you may build the structure one time. Ownership of the construction documents can not be transferred or sold.
• Unless purchasing a printable package, you may not make additional copies of the plan without the permission of the designer.

Plan Packages Explained

Ready to purchase plans and unsure which construction package to choose? We hope the following can help you decide. Please note: Plan packages vary and may not be available on all plans.

1 Set Study Package

This is a single set of prints will allow you to completely review the plan, get accurate quotes for construction costs, and contemplate custom design changes you may wish to make. Study sets are marked Not For Construction and without the license necessary to legally build the home. Don't worry though, we allow a 100% upgrade credit towards a buildable licensed construction package within one year of your 1 Set Study Package purchase.

5 and 8 Set Print Packages

These are licensed print packages of the construction documents printed and shipped to you.

PDF Print Package

This PDF package is a non-modifiable, print only PDF file that saves time, gas, money, and paper! Many contractors and building jurisdictions are working with digital formats of the construction documents. The PDF print package allows for you or your contractor to distribute the construction documents to sub-contractors, use electronic submittals to apply for the building permit, and print the sets you need when you need them.

Plans Now

Don't wait - get your plans NOW! This digital plan package is a downloadable Print PDF Package (non-modifiable, print only). Includes a single build license - electronically signed and emailed to you immediately after placing your order - with permissions to make copies of the plan locally as needed.

PDF Master

An unlocked modifiable PDF file. Same conveniences as the PDF print package with the added benefit which allows your local professional to make engineering mark-ups or design changes using compatible software.

CAD Electronic Files

By using CAD compatible software that use .dwg or .dxf file formats enables you or a local professional to modify the construction documents and integrate those changes throughout the entire plan. Once the modifications or engineering is incorporated into your design, you can reproduce as many copies of the plan needed to build the structure.

Still unsure which package to choose? You may want to discuss this with your builder or give us a call.

How to Evaluate a Plan

When looking at plans, most often it's the exterior profile that will first grab your attention. You love the exterior, it's exactly what you envisioned, but what about the inside of the design? It's important to spend some time and digest the design's interior elements. Here are a few considerations to think about when evaluating if this is the right plan for you.

• First off, think about how you live in your home.
• Do you or your family prefer to have one or two places to gather all together, or do you prefer to have more private places within your home.
• Consider how you move through the home in your day to day life. Visually walk through the front door, what do you walk through or by? Do the same from your back door and garage entrances.
• Is your family life more formal or casual and do the living spaces of the design complement your lifestyle?
• Will your existing furniture fit within the spaces?
• If you have a family, do you want the master suite close to the secondary bedrooms or separated?
• Do you entertain? Are there elements within the floor plan that allow for entertaining with ease?
• How do you take care of laundry? Would you prefer the laundry room to be close by the kitchen, garage, or close to the bedrooms?
• Storage space? Is there enough?
• Consider your access to the outside? Do you want to extend your indoor living to the outside? Is there adequate porches or patios for how you want to enjoy your yard? Where will you place your grill or patio furniture?
• The view? What are you going to see when you look out your windows? Need more privacy or need more accessibility to a view?
• Make sure your garage will accommodate your cars, RV, or boat. Adequate storage? Do you want or need a door to the exterior beyond the opening garage doors? Utility sink? Space for an additional refrigerator or freezer?
• Consider things about your current home/residence that you don't like. By pin pointing these areas of your current home that you don't care for, you can make sure they are addressed in the next.

After reviewing giving it careful consideration you may find that the plan would be perfect with a few design changes. HPC can certainly help you with that with our customization services.

The Customization Process

So you've found that almost perfect design, and find yourself saying, "if only". Whether it's changing the size of a room, adding space or features, or moving things around, we can help you take that almost perfect design and make it perfect for you.

It's exciting to create a plan to fit your exact needs and wants whether it's your home, garage or even a potential investment property.

When you locate your plan, select the "Get Started" button located on the plan detail page. Here you will be able to share with us the changes to the interior and/or the exterior of the design. You can even upload a sketch if you have one. Complete the necessary contact information and select "Submit Request".

HPC will then forward your request to a designer to evaluate your changes and provide a quote within two business days. HPC is a "true quote" plan website. That means HPC will not mark-up the modification quote, we want to help keep costs down for you!

Arnett - 20155

Associated Designs

$0.00

(No reviews yet) Write a Review

SKU:: 101 - 30-419
UPC:
Plan Number:: 20155
Pricing Set Title:: B [1201 - 1499]
Designer Plan Title:: 30-419
Date Added:: 05/23/2016
Date Modified:: 08/06/2024
Designer:: info@associateddesigns.com; jessica@associateddesigns.com
Plan Name:: Arnett
Note Plan Packages: PDF Print Package:: Best Value!
Structure Type:: Single Family
Best Seller (Rank #):: 34
Square Footage: Total Living:: 1211
Square Footage: 1st Floor:: 845
Square Footage: 2nd Floor:: 366
Floors:: 2
FLOORS_filter:: 2
Bedrooms:: 1
BEDROOMS_filter:: 1
Baths Full:: 2
FULL BATHROOMS_filter:: 2
Ridge Height:: 24'
Overall Exterior Depth:: 38
Overall Exterior Width:: 31
Main Floor Ceiling Height:: 8'
Available Foundations:: Crawl Space
Available Foundations:: Concrete Slab
Available Foundations:: Basement
Default Foundation:: Crawl Space
Available Walls:: 2x6 Wood Frame
Default Wall:: 2x6 Wood Frame
Ext Wall Material:: Siding
Lot Type:: Narrow Lot (
Lot Type:: View Lot
Lot Slope:: Level Lot
Roof Framing:: Truss
Snow Roof Load:: 25.00
Roof Pitch:: 8/12
Primary Style:: A-Frame
Secondary Styles:: Cottage
Collections:: Beach House Plans
Collections:: Cabin Plans
Collections:: Vacation Home Plans
Master Suite Features:: Combination Tub/Shower
Master Suite Features:: Exterior Access
Master Suite Features:: Second Floor Master Suite
Master Suite Features:: Separate From Other Bedrooms
Interior Features:: Fireplace/Wood Stove
Interior Features:: Great Room
Interior Features:: Loft
Kitchen Features:: Eating Bar or Peninsula
Kitchen Features:: Walk-In or Wall Pantry
Utility Room Features:: Main Floor Utility Room
Exterior & Porch Features:: Balcony
Exterior & Porch Features:: Covered Porch
Exterior & Porch Features:: Deck
Exterior & Porch Features:: Extended Outdoor Living
Styles:: A-Frame House Plans
Styles:: Cottage House Plans
Collections:: 2 Story House Plans
Collections:: View Lot House Plans
Collections:: Narrow Lot House Plans
Collections:: Small House Plans
Product Rank:: 5006
Note Plan Packages: Master Builder CAD Set:: Unlimited Builds!
Creation Date:: 02/2004
Secondary Styles:: French Country
Styles:: French Country House Plans
Plan SKU:: 30-419
Max Price:: 2575.00
Min Price:: 725.00
Available Walls:: 2x4 Wood Frame

Plan Description

The Arnett is a beautifully designed A-frame home plan, perfect for a vacation retreat. This cozy house plan offers everything a couple or single would need for a relaxing escape. The rear wall, dominated by three high-stacked windows, provides an unparalleled panoramic view of the sea, lake, mountains, or other natural landscapes, making it a true haven for nature lovers.

This vacation home plan is both economical and efficient, designed to be easy to build, heat, and maintain. Its compact footprint, including porches, measures only 31 feet wide and 38 feet deep, making it an ideal choice for those who value simplicity and efficiency. The exterior is adorned with clean-lined batt and boards, while sleek twin columns support the covered porches on the front and side, adding to the overall charm and stability of the structure.

Upon entering, you are greeted by a great room with a lofty, two-story vaulted ceiling, amplifying the sense of space and openness. The room is bathed in natural light from the large stacked windows, creating a warm and inviting atmosphere. A traditional wood stove sits in the corner, providing not only heat but also a cozy spot to warm up after a day of outdoor activities. For added ambiance, owners can choose a wood stove with a glass front, allowing them to enjoy the mesmerizing dance of flames and shadows.

The kitchen, surprisingly spacious for a home of this size, includes a roomy walk-in pantry and plenty of counter space. A raised conversation bar along the edge of the angled peninsula makes it a perfect spot to sit and chat while enjoying the warmth from the wood stove. The kitchen’s open layout ensures that it remains the heart of the home, seamlessly connecting with the great room to facilitate easy interaction and a communal atmosphere.

A hallway lined with storage closets leads to the front porch, bathroom, and a combination utility/hobby room. This versatile space, equipped with laundry appliances hidden behind folding doors, can also double as a guest room when needed. Its flexibility makes it ideal for various uses, from a crafting space to a quiet study area, accommodating the diverse needs of its occupants.

The owners’ suite in the Arnett is designed with flexibility and comfort in mind. The sleeping area can be an open-ended loft or sectioned off for added privacy. The loft, with its elevated position and views through the expansive A-frame windows, creates a serene and picturesque sleeping environment. The owners' bathroom features a luxurious spa tub, offering a touch of luxury and providing a perfect spot to unwind after a long day.

Ideal for those looking for a vacation home plan that combines charm, functionality, and breathtaking views, the Arnett stands out among house plans. Whether nestled by a tranquil lake or perched on a mountain slope, this A-frame home plan ensures a serene and comfortable retreat. Its compact yet efficient design makes it perfect for those who value simplicity and elegance in their living spaces. The Arnett is not just a house; it’s a haven, designed to provide a peaceful and rejuvenating escape from the hustle and bustle of everyday life.

In summary, the Arnett is a beautifully designed A-frame home plan that offers an open floor plan, stunning views, and a practical yet elegant living space. Its thoughtful design and attention to detail make it an ideal choice for anyone seeking a vacation home that embodies both charm and functionality. Whether you’re looking for a seasonal retreat or a year-round sanctuary, the Arnett is sure to meet and exceed your expectations, providing a cozy, inviting, and picturesque home for years to come.
