This detached garage plan can house up to 4 cars if you are willing to park 2 cars deep. The single garage door is 18' wide and 8' tall. If you don't want to park two cars bumper to bumper this design is extra deep and would offer storage or shop space towards the back. In the far left corner is a half bath with room for a storage closet. The stairs lead up to a large loft space which could be finished to fit your needs as an art studio, recreation room, guest suite or whatever else suites.
Plan 53326
Photographs may show modifications made to plans. Copyright owned by designer.
- At a glance
-
2170
Square Feet
-
2
Floors
-
2
- 4
Car Garage
- More about the plan
- Pricing
- Basic Details
- Building Details
- Interior Details
- Garage Details
- See All Details
Contact HPC Experts
Have questions? Help from our plan experts
is just a click away.
To help us answer your questions promptly, please copy and paste the following information in the fields below.
Let’s be social
Connect with us for the latest from HPC
Plan details
Basic Details
Building Details
Interior Details
Garage
What's Included in a Plan Set?
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Concept Plan Packages:
Includes PDF and DWG files of the:
Elevations
Floor Plan (s)
Roof Outline
The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
New to Plan Buying?
53326
Associated Designs
$350.00
- SKU:
- 101 - 20-157
- Plan Number:
- 53326
- Pricing Set Title:
- Garage CAT 3
- Designer Plan Title:
- 20-157
- Date Added:
- 06/08/2017
- Date Modified:
- 01/24/2024
- Designer:
- info@associateddesigns.com; jessica@associateddesigns.com
- Note Plan Packages: PDF Print Package:
- Best Value!
- Note Plan Packages: Plans Now:
- PDF Download!
- Family Plan:
- 20-020
- Structure Type:
- Garage
- Best Seller (Rank #):
- 10000
- Square Footage: Total Living:
- 2170
- Square Footage: Garage:
- 1152
- Square Footage: 2nd Floor:
- 1018
- Floors:
- 2
- FLOORS_filter:
- 2
- Baths Half:
- 1
- HALF BATHROOMS_filter:
- 1
- Ridge Height:
- 24'1"
- Overall Exterior Depth:
- 48
- Overall Exterior Width:
- 36
- Main Floor Ceiling Height:
- 9'
- Available Foundations:
- Concrete Slab
- Default Foundation:
- Concrete Slab
- Available Walls:
- 2x6 Wood Frame
- Default Wall:
- 2x6 Wood Frame
- Ext Wall Material:
- Siding
- Lot Slope:
- Level Lot
- Roof Framing:
- Combination Stick/Truss
- Snow Roof Load:
- 25.00
- Roof Pitch:
- 4/12
- Primary Style:
- Craftsman
- Secondary Styles:
- Country
- Secondary Styles:
- Traditional
- Interior Features:
- Loft
- Garage Orientation:
- Front Entry
- Garage Bays Min:
- 2
- Garage Bays Max:
- 4
- GARAGE BAYS_filter:
- 2
- Garage Features:
- Recreation Room
- Exterior & Porch Features:
- Covered Porch
- Styles:
- Craftsman House Plans
- Styles:
- Country House Plans
- Styles:
- Traditional House Plans
- Collections:
- Plans Now
- Collections:
- 2 Story House Plans
- Collections:
- Garage, Garage w/Living, Carports
- Product Rank:
- 7217
- Note Plan Packages: Master Builder CAD Set:
- Unlimited Builds!
- Creation Date:
- 04/2015
- Plan SKU:
- 20-157
- Max Price:
- 1100.00
- Min Price:
- 350.00
- Regions:
- Northwest House Plans/Oregon Home Plans
